Spring reverb is an early form of synthetic reverb. Similar in principle to plate, spring reverb uses a coiled up piece of metal instead of a flat sheet.
What is Spring Reverb?
A spring reverb unit contains three major components: one to two drivers, metal coils (springs) which are fitted into a pan, and one or two pickups. You may have heard units referred to as “tanks,” which is the combination of the springs inside a metal pan. Spring units can be mono or stereo; it all depends on how they’re configured. Traditionally, spring reverb has been mono in, mono out. However, you can set up a stereo return by adding another tank.
The opposite of plates, which were quite large and extremely heavy, spring reverbs were engineered small enough to fit inside guitar amps.
How Does It Work?
The basic principles of spring reverb is as follows: a transducer first converts an electrical signal to a mechanical one. The mechanical signal, or “motion,” vibrates the spring inside the tank, which then sends a similar wavelength across the coil before mechanically moving a magnet at the opposite end. The magnet creates a current across a pickup, amplifying it into an output signal. All the while, the spring continues to carry the initial wave back and forth.
The initial electrical signal is turned into a decaying waveform by the spring’s movement.
What Does Spring Reverb Sound Like?
Spring units are practically famous for their uniqueness that you don’t quite get from anything else. Of course, as a synthetic reverb, our ear can tell it isn’t replicating a real acoustic space. This is fine, because spring reverb is simply another tool to have in the kit!
Spring reverb is most often described as “bouncy.” It’s easy enough to imagine that a vibrating coil would certainly have this texture. Remember those tightly coiled doorstops you would flick as a kid? The concept is very similar!
The bounciness we hear comes from the actual timing between echoes in the tank. To create each artificial reflection, the signal must first travel the length of the spring to the transducer, bounce back across the length of the coil, and again bounce across the full length of the spring back to the transducer.
Spring units are also typically low-end focused because of the way a signal vibrates the coil. Higher frequencies have shorter wavelengths which may not be able to travel the full length of the spring, moving only single coils at a time. Lower frequencies, with their longer wavelengths, have the power to move multiple coils at once, meaning we get more low end from spring reverb.
Using Spring Reverb in Mixes
Synthetic reverbs like spring and plate are similar in their uses. Instead of using them the “normal” way, as in creating an acoustic space for mix elements to live, spring reverb is more often used to add color, create an effect, or to fill out other reverbs like chambers, halls, or rooms. Always remember that there’s no right or wrong approach to anything, and that your mixes are only limited by what sounds good! So definitely experiment and test spring reverb on anything and everything.
Spring reverbs are great for adding perceived low end to an instrument. Like we discussed earlier, lower frequencies have the power to vibrate multiple coils simultaneously, overpowering the shorter wavelengths that may only move a single coil at a time.
If you want to add a bottom-heavy dimension with your reverb, spring is a solid choice.
Our ears are very adept at determining whether a sound is natural. Because of this, we instinctively know whether a reverb is coming from an actual physical space, or some place unnatural. Spring reverb is synthetic, and our ear knows this! But that’s okay, because springs can be used as an effect.
Mixing music isn’t always about realism! Depending on the material, sometimes the most outlandish and unusual sounds are the perfect fit for the track. Consider using spring tanks when you aren’t concerned with creating a space that sounds “real.”
Blend It with Other Reverbs
It’s incredibly common to use multiple reverbs while mixing. If you mix from a template, for instance, you might already have chamber, hall, room, plates, and springs set up and ready to go, adding a bit of each to taste as you mix.
Springs are great to blend with other reverbs, because they have a totally different quality from a dedicated space. On a totally dry track, you can pick a space, like a room or hall, and then augment that with plate instead of another room. This ensures you won’t be creating a “room within a room” vibe.
Think about it on drums. If they were recorded in a live space, you’ll have natural reverb already printed. Rather than adding a “drum room” reverb emulation to a real drum room, you can mix in some spring instead.
